Drive Axle Forklift

Forklift Drive Axle - The piece of equipment that is elastically fastened to the frame of the vehicle utilizing a lift mast is called the lift truck drive axle. The lift mast attaches to the drive axle and can be inclined, by at the very least one tilting cylinder, around the drive axle's axial centerline. Forward bearing parts combined with rear bearing parts of a torque bearing system are responsible for fastening the drive axle to the vehicle framework. The drive axle can be pivoted round a swiveling axis oriented transversely and horizontally in the vicinity of the back bearing parts. The lift mast can also be inclined relative to the drive axle. The tilting cylinder is connected to the lift truck frame and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented nearly parallel to a plane extending from the axial centerline and to the swiveling axis.

Forklift models like for example H35, H40 and H45 that are manufactured in Aschaffenburg, Germany by Linde AG, have the lift mast tilt capably affixed\connected on the vehicle framework. The drive axle is elastically affixed to the lift truck framework using a multitude of bearing tools. The drive axle has tubular axle body along with extension arms connected to it and extend rearwards. This kind of drive axle is elastically attached to the vehicle frame using rear bearing elements on the extension arms together with forward bearing devices located on the axle body. There are two rear and two front bearing tools. Each one is separated in the transverse direction of the forklift from the other bearing tool in its respective pair.

The drive and braking torques of the drive axle on tis particular model of forklift are sustained by the extension arms through the back bearing components on the frame. The forces generated by the load being carried and the lift mast are transmitted into the floor or road by the vehicle framework through the front bearing elements of the drive axle. It is vital to ensure the elements of the drive axle are installed in a rigid enough way to be able to maintain stability of the lift truck truck. The bearing components can lessen small bumps or road surface irregularities during travel to a limited extent and give a bit smoother function.
